IP67, Class I. IK08. Marine-grade all aluminium construction. Anodized aluminum extrusion. PCS hardware. Silicone rubber gasket. Safety glass lens; max. load 5 tonnes.
Luminaire can be driven over at low speed. Factory-sealed termination chamber complete with cable gland and 0.5 m of flexible cable. Linear PMMA LED lens. Factory installed LED circuit board. LED boards can be easily removed for upgrading. Luminaire is factory-sealed and does not need to be opened during installation. The installation blockout to be ordered separately.
Material
Body
Marine-grade all aluminium construction. Anodized aluminium extrusion.
Fasteners
PCS polymer coated stainless steele
Gasket
Silicone rubber gasket
Impact Protection
IK08
Ingress Protection
IP67
Lens
Safety glass lens
Corrosion Protection
5CE
Listings
ETL Listed. Suitable fo wet locations.
Driver / Ballast
Electronic converter
Power Factor
> 0.9
Power Supply
Integral [ECG] electronic driver 120V-277V. 0-10V Dimming.
LED >60,000 h Ta 25°(L70/B10)
Control gear >50,000 h Ta 25°
